16 Pair Digital Snake Cable

PART NO : SNK-DIG-16P

Configuration: 16 Pair Digital Snake Cable
Conductor: 24 AWG – 19/0.12 mm Annealed Bare Copper (ABC)
Core Construction: 2 Core per Pair
Insulation: High-Density Polyethylene (HDPE) insulated
Core Formation: Twisted Pair in Circular Form
Tape Layer: Mylar Polyester Tape for Enhanced Stability and Insulation
Shielding: Dual Shield – Aluminium Foil + ABC Spiral Shield for Maximum EMI/RFI Protection
Inner Sheath: High Flex special rubberized PVC
Outer Jacket: Satin touch, matt finish, high-flex, special PVC jacket

Request Quote

Premium Features

Explore the advanced engineering behind every Krystals Cables and see how each feature elevates performance and outperform industry standards.

High Conductivity ABC Copper

High conductivity of Annealed Bare Copper conductor (19 wires of 0.12mm)

65-wire Spiral (Helical) Shield

Advanced and dense Spiral (Helical) Shielding with Bare Wires (65 wires of 0.09mm) provides superior protection against electromagnetic interference.

100% Shielding Coverage

Tripple Shielding with Bare Copper Wires Spiral shield + aluminum foil gives a complete shield achieving coverage of more than 100% on individually twisted shielded pairs

Channel Number Identification

Each pair within is individually numbered and printed on its pair jacket, allowing for quick and accurate channel identification during installation and maintenance

Fire Retardant PVC

The fire-retardant PVC used in Krystals’ cables is specially engineered to resist ignition and prevent the spread of flames, offering an extra layer of protection in case of electrical faults or overheating

DMX Applicable

This cable maintains a characteristic impedance of 110 Ω (ohms) to ensure accurate signal transmission and minimal data loss in DMX512 applications.

Clear Sound Quality

Delivers excellent audio reproduction with minimal distortion, due to big cross-sectional area and ABC copper conductor

Highly Flexible

Engineered with fine-stranded conductors and soft, durable jackets, these cables offer exceptional flexibility and long-lasting performance

Double Shielding

Equipped with aluminium foil, mylar tape, and copper braid, the double-layer shielding delivers maximum protection against interference, ensuring clean, noise-free signal transmission even in high-interference environments.

dummy text

Available Packaging

Choose the right size for your installation needs

100m Coil
